High precision horizontal Cnc lathe Machine CK6150, High Speed turning Center. There are many models in the Chinese lathe market
For example SK40P, SK40S, SK50P, SK50S =CK6140 and CK6150 .ck6150 factory direct low price in China.CK Series lathe For heavy-duty cutting of large specifications and heavy-weight work. Shift gears, Infinite variable speed, Constant Linear speed cutting.
CK6150 Lathe Features Description
1. High Speed and high efficiency
2. Turning substitutes for grinding
3. All Servo system control.
4. Spindle Bore:82mm and 105mm
5. Different length of the machine is available:750mm/1000mm/1500mm/2000mm/3000mm
6. Optional control systems: FANUC, GSK, KND, HNC, Siemens.
CK6150 Lathe Specification
| itm | unit | CK6150F | |
| Machining Range | Max. Swing over bed | MM | 500 |
| Max. Swing over cross slide | MM | 300 | |
| Max. Z axis Travel | MM | 750/1000/1500/2000 | |
| Max. X axis Travel | MM | 3000 | |
| Spindle | Spindle bore | MM | 82 |
| Spindle nose | A2-8 | ||
| Spindle speed range | RPM | 45-260/140-800/550-1600 or 60-1600 | |
| Spindle speed steps | independent spindle or 3 steps | ||
| Chuck | MM | Manual 3 jaw 250 | |
| Lathe bed | Bed width | MM | 400 |
| Feed | x/z fast feed | Mm/ min | 6000/8000 |
| x/z cutting travel speed | Mm/ min | 1-6000 | |
| Tool Turret | Number of tool turret | 4/6/8 | |
| Tool shank type | MM | 25*25 | |
| Working accuracy | Positioning accuracy | MM | X≤0.010 Z ≤0.015 |
| Repeatability Positioning accuracy | MM | X≤0.0075 Z ≤0.010 | |
| Min. unit set | MM | 0.001 | |
| roundness | MM | ≤0.007 | |
| Diameter uniformity | MM | ≤0.03 L:300 | |
| Flatness | MM | ≤0.02Dia,300 | |
| roughness | Ra1.6um | ||
| Tailstock | Dia. of tailstock sleeve | MM | 85 |
| Tailstock sleeve taper | MT5 | ||
| Max. Tailstock sleeve travel | MM | 130 | |
| Motor | Spindle drive motor power | KW | 7.5 |
| Coolant pump power | W | 120 | |
| weight | KGS | 2300/2500/2900/3500 | |
