CA6150 Horizontal Lathe
CA6140 series ordinary horizontal lathes China manufacturer are suitable for turning internal and external cylindrical surfaces, conical surfaces and other rotating surfaces, turning various metric, inch, modulus and diametral pitch threads, and can perform drilling and pulling oil grooves, etc. CA6150-1500 Horizontal Lathe is very versatile. The horizontal lathe is widely used in batch processing of various shaft and disk parts.
The bed of this series of lathes is wider than ordinary lathes, and the width of the guide rail is 400mm, which has high rigidity. The surface of the guide rail is quenched by intermediate frequency, which is durable and wear-resistant.
The operation of the machine tool is flexible and centralized, and the sliding plate is equipped with a fast-moving mechanism. CA6150-1500 Horizontal Lathe adopts single-handle visual operation, which is pleasant.
The structural rigidity and transmission rigidity of the machine tool is higher than that of ordinary lathes, and the power utilization rate is high, which is suitable for strong cutting.
Before leaving the factory, the machine tool is inspected in strict accordance with the inspection procedures, and a strong cutting test is done to ensure that the machine tool has good precision stability and processing reliability.
CA6150 Horizontal Lathe advantages of machine tools
- Manual scraping and grinding between the joint surfaces of the bed head box, the bed, the tailstock, the pallet, etc., and the whole machine has been strictly tested to effectively ensure the accuracy and stability of the machine tool.
- The machine tool is made of high-strength cast iron, with copper and chromium special materials added, the width of the bed guide rail is 400mm, and the quenching depth of the bed guide rail reaches 4mm, which effectively improves the wear resistance and stability of the machine tool.
- The cycloidal pump is used for the lubrication of the bedside box of the machine tool, which ensures the cleanliness and heat dissipation characteristics of the bedside box for the hot weather in the south and effectively prolongs the service life of the bearings and gears.
- The spindle of the machine tool adopts Wafangdian bearings, the through hole of the spindle is φ52/80mm, and the gears of the machine tool are precision ground, which effectively improves the hardness of the gears and reduces the noise of the machine tool.
- The machine tool adopts a domestic brand lead screw, and the screw nut adopts high-quality bronze alloy to ensure wear resistance and precision retention.
- The machine tool adopts a four-station high-strength tool holder and the size of the tool handle: is 25x25mm.
CA6150-1500 Horizontal Lathe technical parameters
| SPECIFICATIONS | Units | CW6150x1500 |
| Max.Swing over bed | mm | 500 |
| Max.Swing over cross slide | mm | 300 |
| Max.length of work piece | mm | 1500 |
| width of bed | mm | 400 |
| Section of turning tool | mm | 25×25 |
| Spindle speed | rpm | 16-1400(24steps) |
| Hole through spindle | mm | Ф52 |
| Spindle taper | – | NO6(MT6) |
| No. Of feed | – | 64kinds |
| Range of metric threads | – | (1-192mm)44kinds |
| Range of inch threads | – | (1-24tpi)21kinds |
| Range of module threads | – | 0.25-48/39kinds |
| Range of dianetral pitc threads | – | 1-96DP/37kinds |
| Max.tailstock spindle travel | mm | 150 |
| Tailstock spindle diameter | mm | Ф75 |
| Taper of tailstock spindle center hole | – | NO.5(MT5) |
| Main motor | kw | 7.5 |
