CA6161 Common lathe is a machine tool used to shape and cut materials in metalworking and woodworking applications. There are many different types of lathes, but the most common type is the ordinary lathe, also known as a metalworking lathe or a turning lathe. In this article, we will discuss what an common lathe is, how it works, and its main uses.
CA Manual lathe CA62 gap lathe | ||||||
ITM | UNIT | CA6140 CA6240 | CA6150 CA6250 | CA6161 CA6261 | CA6166 CA6266 | CA6180 CA6280 |
Max.swing over bed | mm | 400 | 500 | 610 | 660 | 800 |
Max.swing over carriage | mm | 210 | 300 | 370 | 400 | 540 |
Max.swing in gap | mm | 630 | 720 | 830 | 880 | 1020 |
Max.swing length | mm | 210 | 210 | 210 | 210 | 210 |
Effective gap length | mm | 750/1000/1500/2000/3000/4000 | ||||
Width of lathe bed | mm | 400 | ||||
Section of turning tool | mm | 25*25 | ||||
Spindle speed | rpm | 16-1400 (24steps) | ||||
Spindle bore | mm | 52/80/105 | ||||
Spindle nose | 52bore: ISO(GB)C6 (80/105 bore:D8) | |||||
Spindle taper | 52Bore:No.6 MT6 ,80Bore: 1:20 105Bore: 1:20 | |||||
No.of feed | 64kinds | |||||
Range of metric threads | mm | 1-192mm 44 kinds | ||||
Range of inch threads | tpi | 1-24tpi 21kinds | ||||
Range of module threads | 0.25-48module 39kinds | |||||
Range of diametral threads | DP | 1-96DP 37kinds | ||||
Max.tailstock travel | mm | 150mm | ||||
Tailstock Diameter | mm | 75mm | ||||
Taper of tailstock hole | MT5 | |||||
Main motor | kw | 7.5 10HP |
